BRAZING
Facilities are available for brazing components, in vacuum, or reducing atmosphere, up to 250mm diameter × 300mm long. The braze material normally employed will be Silver/Copper eutectic. This preferred material produces a high seal strength at low cost. For applications where higher operating temperatures or other design constraints are involved, Gold/Copper, Gold/Nickel or Copper braze materials are employed, the latter braze material having a liquidus point of approximately 1100°C.

mbar	VAPOUR PRESSURE OF BRAZE ALLOYS
1 x 10-9
1 x 10-8
1 x 10-7
1 x 10-6
1 x 10-5
1 x 10-4
1 x 10-3
1 x 10-2

600	700	800	900	1000	1100	1200
	Temperature °C
